| Processor | Texas Instruments AM3505 (600 Mhz) |
| Memory | Flash 512 MB; DRAM 256 MB |
| Operating System | Linux |
| Firmware Upgrade | Web-based and remote firmware upgrade capabilities |
| Management Protocols | RM 1.0.1 (with XML over HTTP/HTTPS and SNMP binding); RDMP |
| Network Services | DHCP, HTTPS, FTPS, SFPT, SSH, HTTP, FTP, SNMP and NTP |
| Network Stack | IPv4 and IPv6 |
| Security | Transport Layer Security Ver 1.2, FIPS-140 |
| Air Protocols | EPCglobal UHF Class 1 Gen2, ISO 18000-6C |
| Frequency (UHF Band) | Global Reader: 902 MHz – 928 MHz (Maximum, supports countries that use a part of this band), 865 MHz – 868 MHz US (only) Reader: 902 MHz – 928 MHz |
| Transmit Power Output | 10 dBm to +31.5 dBm (POE+, 12V ~ 48V External DC, Universal 24V DC Power Supply); +10 dBm to +30.0 dBm (POE) |
| Max. Receive Sensitivity | -82 dBm |
| IP addressing | Static and Dynamic |
| Host Interface Protocol | LLRP |
| API Support | Host Applications – .NET, C and Java EMDK; Embedded Applications – C & Java SDK |
